Détails sur le produit:
|
| Utilisation: | Chaîne de production de SMT | Garantie: | 12 mois |
|---|---|---|---|
| Application: | Chaîne de production d'Assemblée de carte PCB de SMT | Taille de carte PCB: | 350x250mm (pourrait être adapté aux besoins du client) |
| Puissance: | 220/110V | NOM: | Machine de manipulation de carte PCB |
| Surligner: | machine de manipulation de carte PCB de la barre 220V 6,machine de manipulation de carte PCB de SMEMA,déchargeur de chargeur de carte PCB de 90 degrés |
||
PCB Handling Machine SMT Automatic 90 Degree Turning Machine
Product Description
Solid and stable design
Stable and reliable integrated control system
HMI control panel, easier operation
Enclosed design with built-in torque limiter ensures highest level of safety
The top cover can be opened to facilitate the maintenance of machine
90 degrees or pass through for optional
Machine always fault monitoring
SMEMA compatible
Specifications:
| Model No | SMTZT-250 | SMTZT-350 |
| PCB Size(mm) | (50x50)-(350x250) | (50x50)-(460x330) |
| Machine Size(mm) | 600x650x1300 | 700x750x1300 |
| Weight(kg) | 170 | 195 |
Technical Parameters:
| Function | Cycle Time | Power Supply | Air Pressure |
| It is used to change direction in production line | Approx 15 seconds | 100-230V, 1PH, Max 300VA | 4-6Bar |
| Transport Height | Transportation Direction | Air Consumption | PCB Thickness |
| 900±20mm(or customized) | L to R or R to L | Max 15L/Min | Min 0.6mm |
PCB Transport Direction:
Packaging:
1. Fix the machine base on the wooden base by screws
2. Vacuum
3. Package into a wooden case
Delivery Terms:
1. Ex-work/FOB/CIF/DDU, up to clients
2. Production leadtime: 3-7 days
