Détails sur le produit:
|
| Tension: | 220Vac | Condition: | Nouveau |
|---|---|---|---|
| Épaisseur de carte PCB: | 1,0 à 3.5mm | Garantie: | un an |
| Longueur de coupe maximum: | Illimité | Nom de produit: | Machine à lames multiples de carte PCB Depaneling |
| Surligner: | Machine de cisaillement de carte PCB de couteau multi de trancheuse,machine de cisaillement de carte PCB de 3.5mm,12 groupes de lame de coupeur de carte PCB Depaneling |
||
Multi Slicer PCB Cutting Machine PCB Shearing Machine 12 Groups Blades
Multi-blade PCB Depaneling Machine Features:
1. It can cut many boards with multiple sets of knives work at the same time.
2. The knife flywheel is adjustable as a whole from 0 to 5mm
3. The distance between knives is regulable as well, satisfy to cutting the single PCB width from 15mm-20mm
4. The blade is made of Japan imported high speed and high precision steel material, which is durable and have a long service life.
5. It is convenient to adjust the cutting speed through rotary knob
6. No limits of the cutting length.
7. Thickness range of PCB: 0.8-3.5mm
8. With a conveyor belt line, the separated PCB can be send out directly to reduce pick- and-place.
9. The machine adopts multiple blade to separate boards with simple operation and high efficiency.
10. It can connect the production line to separate the PCB, fitted for batch production.
Multi-blade PCB Depaneling Machine Specification:
| Max cutting length | No limit |
| Min cutting length | 100mm |
| Max panel width | 220mm |
| Custom cutting width | 300mm |
| Min PCB width | 8mm |
| PCB thickness | 0.8-3.5mm |
| Feeding speed | 0-500mm/s |
| Working tem. | 10-35℃ |
| Blade material(auto-lock function) | Imported high precision steel |
| Storge tem. | -20-50℃ |
| Voltage | 110-220V |
| Dimension | 2160*570*1050mm |
Self-Lock Blades:
Multi-blade PCB Depaneling Machine Details:
